Product Description:
QSFP28 100GBase CWDM4 Duplex LC, Single-mode Fiber (SMF) 1271nm-1331nm, 2 Km (1.24 miles), DOM, Commercial Temperature
Form Factor: Quad Small Form Factor Pluggable Twenty Eight - QSFP28 |
TOSA & Wavelength: DML (DFB) CWDM Laser @ (1271nm, 1291nm, 1311nm, 1331nm) |
Cable and Connector Type: Singlemode over Duplex Fiber |
Max Distance: 2 Kilometers (1.24 Miles) over OS2 Fiber |
Data Rate: 103.125 Gb/s Bit Rate (4 x 25.78 Gb/s) |
Temperature Rate: Commercial Temperature: 0°C to 70°C |
TX Power: Min: -6.3dBm ~ Max: +2.2dBm |
RX Sensitivity: -11.5dBm |
Power Consumption & Budget: <3.5W / 5dB |
Digital Diagnostic Supported: Yes (DDM/DOM) |
